10W Waterproof Indoor Led Downlights , 120lm / W Dimmable
Downlights COB CREE LEDS
Description:
MingFeng, as a prominent China LED down light manufacotry, devotes
himself to providing high quality Dimmable LED down lights for the
replacement of traditional down lights in residential, museum,
office and commercial applications.
MF Production is carried out under a complete quality testing
system. Inspection is performed prior to manufacturing and during
the production process, each light goes through very rigorous aging
tests, to guarantee a long service life.General products are
delivered with a 5 years qualitywarranty. Certain product lines are
coveredwith a 10 years warranty.The sample delivery time for
general products is about a week and will be no more than two weeks
for bulk production.We have eliminated the middleman segment of the
sales process and we will work directly with customers to complete
large scale orders and this allows us to ensure low prices.
Applications:
The E esries of waterproof led ceiling down lights are widely used
in schools, hospitals, offices, shopping malls, social gathering
areas, bathrooms and other stores for a bright, welcoming
appearance.
Technical Parameters: MF-E300098
Spec -10 & 12W.pdf
| Input voltage | 220-240Vac, 50hz/60hz |
| Product Size | D109*52mm |
| Cut out Size | ￠98mm |
| Power(watt) | 10W/ 12W |
| Color temperature | 3000K / 4000K / 6000K |
| LED Chip | Cree COB/ Epistar COB |
| LED Driver | Lifud (IP44) / Meanwell (IP65) |
| PF | ≥0.95 |
| Housing Colour | White RAL9003 |
| Luminous Flux (lm) | 10W: 800lm@3000K, 900lm@4000K, 960lm@5000K 12W: 960lm@3000K, 1000lm@4000K, 1100lm@5000K |
| CRI(Ra) | >83 |
| Lifespan | ≥50000hrs |
| Beam Angle | 40° |
| Material | Aluminum |
| Operating Temperature | -200C ~500C |
| Dimmable | Y |
| IP | IP44/IP65 |
| Certificate | CE/ RoHS |
| Warranty Period | 3 years |
3", 3.5", 4"
5", 6", 8"
Competitive Advantage:
A. Light Source: We Utilize the latest technology in highly efficient COB CREE
light emitting diodes. The output efficiency ranges between 100 to
120lm/w, with a color rendering index reaching upwards of more than
85.
B. Reflection ring: This ring is made of a highly reflective material with a
reflectivity of more than 95%.
C. Power Supply: We use Japanes LIFUD power supply or Taiwanese MEANWELL waterproof
power supplies, offering a power factor of more than 0.95. This
power supply also features a stable quality that extends the
service life of the light.
D. Cover: UGR<19 The transparent glass cover guarantees visual comfort.
E. Connector: The connector is equipped with a hermaphrodite connectro that is
easy to install. This connector can be adjusted to different levels
based on different application needs.
F: Radiator: The high quality die-cast aluminum material used for the radiator
provides an LED light source with a stable operation environment,
thus ensuring long term, reliable operation.
G. Installation Fastener: The installation fastener has undergone a special corrosion
resistant treatment in order to fully support the light.
H: Ring:The ring meets RAL9003 standards, and is sprayed with a coating of
white paint to ensure it has a pleasing appearance. If customers
require othe colors, we can customize light options with a variety
of colors to meet those needs.
