Epistar COB 5W CE RoHS Alu. PC Anti Glare IP40 Round Recessed Light Spotlight Ceiling Mounted Down Light High luminous efficacy
Direct replacement for compact fluorescent lamp downlights
Energy savings up to 60 %
(compared to luminaires that use CFL lamps)
Very homogenous light
Functional design
Easy installation with fast connection
3 years guarantee
Diameter of required ceiling
cut-out:55mm,75mm,95mm,60mm,80mm,100mm Type of protection, back side: IP40
Type of protection, front side: IP44
Reflector Color
Electrical data | Nominal wattage | 5W / 10W / 18W |
| Nominal voltage | 100.…240 v |
| Mains frequency | 50…60 Hz |
| Nominal current | 350.000 mA |
| Power factor λ | 0.90 |
| Protection class | II |
| Operating mode | Electronic control gear (ECG) |
Photometrical data | Luminous flux | 5W 500lm / 10W 1000lm/ 18W 1800lm |
| Luminous efficacy | 100 lm/W |
| Color temperature | 3000 K 4500K 6000 K |
| Light color (designation) | Warm White |
| Color rendering index Ra | ≥80 |
| Beam angle | 8°/15°/24°/36°/60° |
Dimensions & Weight
Materials & Colors | Product color(Ring) | White |
| Housing color | Grey |
| Body material | Aluminum |
| Mercury content | 0.0 mg |
Application & Mounting | Ambient temperature range | -20…+40 ºC |
| Type of connection | Terminal,2-pin |
| Type of protection | IP40 |
| Dimmable | No |
| Mounting type | Recessed |
| Mounting location | Ceiling |
| Application environment | Indoor |
| Mounting diameter | Refer to Dimensions & Weight |
| LED module replaceable | Not replaceable |
Lifespan | Lifespan L70/B50 at 25ºC | 30000 hr |
| Number of switching cycle | 15000 |
| Luminous Flux | 5W 7500lm / 10W 1000lm/ 18W 1800lm x1x2x3x4x6 |
| Luminous Efficacy | 100 lm/W |
| Color Temperature | 3000K 4000K 6000K |
| Light Color (designation) | Warm White |
| CRI | ≥80 |
| Beam Angle | 15°/24°/36° |
LED downlights are commonly used indoors in residential, commercial, public, and industrial spaces. They provide efficient and effective lighting for living areas, bedrooms, kitchens, offices, retail stores, restaurants, hotels, schools, libraries, hospitals, warehouses, and factories. LED downlights are popular due to their energy efficiency, long lifespan, and versatility, and can be customized to provide different light color, brightness, and beam angles to meet different needs.
The mentioned product code describes the smallest quantity unit which can be ordered. One shipping unit can contain one or more single products.
When placing an order, for the quantity please enter single or multiples of a shipping unit.
