ElectrostaicLighting SurgeFlash CharacteristicVertical DivergenceIntensity
IP66 AC110-240V LED Aircraft Warning Red Beacon Aeronautical Aviation Obstacle Light for Power Transmission Tower Wind Turbine Control Tower

Electrical

1.CREE ultra high intensity LED as light source saving power consumption and maintenance than incandescent light or halogen

lamp

2.Power supply in DC(48V)& AC(110-240VAC), the light could work normally when input 48VDC/110VAC/240VAC

Physical

1.Unique design and UV protected polycarbonate reflector for converging light

2.UV protection Powder coated bright yellow color base make better visibility

3.Base material is die casting aluminum which has strong corrosion resistance, Shock and Vibrations protection

4.Pressure equalizing valve installed under the base to make sure the air could go through but water is avoid, so

that the whole light temperature won't be high to avoid the moist air enter due to pressure and temperature difference.

System design

1.Built-in photocell for day/night operation(dusk to dawn operation, automatically turn on when background luminance is below

50cd/m2

2.Surge and lightning protection

Optional

1.Dry contact Alarm output for remote monitoring

2.GPS synchronization

3.Infrared LED for pilot using NVG

Compliance

ICAO Annex 14 Volume 1, Eight edition, 2018, table 6.3 Medium Intensity Type A, Medium Intensity Type B/C Obstruction Light

FAA L-865 & FAA L-864

1.High-rise Buildings: Applicable for the top of high-rise buildings to alert low-flying aircraft. 2.Communication Towers: Used to mark the top of communication towers to prevent collisions with low-flying aircraft. 3.Chimneys: Suitable for the top of chimneys to warn pilots of their altitude. Wind Turbines: Applied to the tips of wind turbine blades to alert low-flying aircraft. 4.High Poles: Applicable for the top of lamp posts, traffic surveillance poles, and other tall pole structures. Tower Cranes: Used for the top of tower cranes to alert low-flying aircraft.

The obstruction light can be used alone or in combination with low-intensity lights and medium-intensity Class B lights to create a comprehensive aviation obstruction lighting system. Its intelligent design greatly reduces daily maintenance work, making it an ideal solution for aviation obstruction lights.
