FEATURES
1.IP66 Waterproof/dust proof/explosion proof/IK08
2.Pure Aluminum shape good at heat dissipation
3.Angle Bracket,easy to install by drill
4.Easy replacement and installation
5.Phi-lips SMD 3030 Ra>80/ R9>0/ SDCM<6
6.100,000 times switching cycle before failure
7.Total harmonic distortion(THD)<15%
Matters needing attention
1.Before installing the lighting fixtures,please read this
instruction manual carefully.
2.The lighting fixtures should be intalled,connected and tested by
certified electrician based on the local regulations
3.Lamps should always be installed or replaced carefully
4.Please check the local voltage in accordance with the product
requirements before installation
5.Revamping only can be done when the power is off and the lamp is
completely cooled down
6.When clean the lamp,make the power off and let it cool down
completely,clean the fixture with a soft colth and a standard PH
neutral detergent,stainless steel should be maintained regularly.
7.Don't cover the fixtures with flameable materials
8.Replace shouldbe made by the manufaturer or his service agent or
certified electrician in order to avoid a hazard
Temperature Characteristics t-ambient 25ºC.
Temperature
Operating -20~+45ºC
Storage -40~+60ºC
Electrical CharacteristicsInput Voltage:AC100-277V 50/60Hz
PF:>0.93
Power Efficiency:>=0.90
| Model NO. | Power(W) | Light Source | LED QTY(pcs) | CCT(K) | Lumen(lm/w) | CRI | Beam Angle |
| 20W | 20 | 3030 | 16 |
4000K
|
130
|
>70/80
|
120°
|
| 30W | 30 | 32 |
| 50W | 50 | 48 |
| 100W | 100 | 96 |
| 150W | 150 | 160 |
| 200W | 200 | 240 |
| 250W | 250 | 240 |
| 300W | 300 | 320 |
| 400W | 400 | 510 |
Outdoor Area Lighting:
LED flood lights are widely used to illuminate large outdoor areas
such as parking lots, stadiums, sports fields, and industrial
yards. They provide bright and uniform lighting, enhancing safety
and visibility.
Building Facades and Monuments:
LED flood lights are used to highlight architectural features,
facades, and monuments of commercial buildings. They can be
strategically positioned to create dramatic lighting effects and
draw attention to the structure.
Signage and Billboards:
LED flood lights are ideal for illuminating signage and billboards.
They offer high brightness and uniform light distribution, ensuring
clear visibility of advertisements and promotional messages, even
from a distance.
Warehouses and Industrial Facilities:
LED flood lights are commonly used in warehouses, factories, and
industrial facilities to provide bright, well-distributed lighting
for improved safety and productivity. They can be mounted on high
ceilings to cover large areas effectively.
Retail Spaces:
LED flood lights are employed in retail stores, shopping malls, and
showrooms to create an inviting ambiance and highlight product
displays. They can be used to accentuate specific areas or
products, enhancing the overall shopping experience.
Outdoor Events and Festivals:
LED flood lights are extensively used for temporary lighting setups
during outdoor events, festivals, concerts, and exhibitions. They
offer high-intensity lighting that can be customized to suit
different requirements.
Security Lighting:
LED flood lights play a crucial role in commercial security
applications. They are used to illuminate parking lots, building
perimeters, and sensitive areas to deter intruders and enhance
surveillance camera visibility.
Sports Lighting:
LED flood lights are widely used for sports field lighting,
including football fields, tennis courts, basketball courts, and
outdoor recreational spaces. They provide high-quality lighting,
ensuring optimal visibility for players and audiences.
Hospitality and Hotels:
LED flood lights are employed in hotels, resorts, and hospitality
establishments to illuminate outdoor areas, including gardens,
pathways, and entrances. They create a welcoming environment and
enhance safety for guests.
Exhibition and Trade Shows:
LED flood lights are popular for illuminating exhibition booths and
trade show displays. They can be easily installed and adjusted to
highlight specific products or create a desired atmosphere.
