Lighting Date
LED Type	Cree
System Efficacy	100lm/W±5%
System Power Consumption	15W/20W/30W/50W
CCT	2700K 3000K 4000K 5000K
Beam Angle	60°
CRI	Ra80/Ra90
System Efficiency	>90%
SDCM	<5

​​

Electrical Data
Power Supply	CE/Lifud
Input voltage	100-240V AC
Power Frequency	50-60Hz
Output Voltage	28.8-48VDC
Output Current	350mA~2.0A
Power Efficiency	>90%
Power Factor	>0.90
Total Harmonic Distortion	<20%

​​

Material Data
Fixture Material	Alu.+PC
Paintings	AkzoNobel
Class rate	Class I
Ingress Protection	IP65
Dimmable	1~10V Dim/DALi as options
Life Span	7 years at 12 hours/day

​

​​

​

LED downlights provide numerous benefits, including energy savings, longer lifespan, instant-on capability, and flexibility in terms of color temperature and dimming options. They are a versatile lighting solution for various residential, commercial, and outdoor applications.
Outdoor Lighting:
Waterproof and weather-resistant LED downlights are suitable for outdoor applications. They can be used to illuminate building exteriors, pathways, gardens, patios, and decks, enhancing safety and creating an inviting outdoor ambiance.
Task Lighting:
LED downlights with adjustable heads or gimbal designs are often used for task lighting purposes. They can be installed in kitchens, offices, and workspaces to provide focused illumination on countertops, desks, or specific work areas.
Accent Lighting:
LED downlights can be used to create dramatic lighting effects and highlight architectural features, sculptures, or decorative elements in both residential and commercial settings. They add depth and visual interest to the space.

​

	MF-D1001B	MF-D1002B
Junction Temperature(Tj)	<70°C(Ta=30°C)
Storage Temperature	-40~+60°C
Operating Temperature	-40~+40°C
Outlook Size(MM)	15W,110xH59mm;20W, 127xH70mm;30W, 165xH80mm,50W,220xH90mm	15W,L110xW110xH59mm; 20W,L127xW127xH70mm; 30W,L165xW165xH80mm; 50W,L220xW220xH90mm
Cutting Size(MM)	15W,100mm;20W,110mm;30W, 145mm,50W,200mm	15W,L90xW90mm; 20W,L110xW110mm; 30W,L145xW145mm; 50W,L200xW200mm;
Export Carton Size	Refer to specified data sheet

​​​

FAQ:

Q1: What do you sell?
A1: We provide good quality of floodlight, high bay light, explosion proof light, tri-proof light, downlight, and other lighting products, as well as responsible services and reliable after-sales warranty.

Q2: Is it OK to print my logo on led light product?
A2: Yes. We provide ODM and OEM services. Please inform us formally before our production and confirm the design firstly based on our sample.

Q3: How to deal with the faulty?
A3: During the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.

Q4: Can I have a sample order for led light?
A4: Yes, we welcome sample order to test and check quality. One sample or mixed samples are acceptable.

Q5: How long time to ship the goods if place an order?
A5: Usually 7 days for sample or small order,15 working days for bulk order, but sometimes depend on the order quantity.

Ming Feng Lighting Co.,Ltd is one of the leading LED light product, located in Guangdong Province, China.  Established in year 2009 and has more than 15 years experience in exporting LED lighting products. Ming Feng LED lighting factory produce LED Indoor Light and LED outdoor lamp. For the LED indoor light, we are producing the LED Triproof Lights, LED Vapor Tight Lights,LED down lights ,LED Flat panel, For the Outdoor LED Light, we are producing the LED flood light, LED high bay lighting, LED stadium lights,outdoor LED landscape light and some of LED Aviation Obstruction light, LED Search light.With the rapid growth of our sales volume in the market, our R&D are expanding quickly to meet the market demands.

Our Company established a quality management system in accordance with the ISO9001 standard. Procuct are CE, CB,ROHS,SAA, ETL,DLC certificed.Our main market is in European, North American, and Southeast Asia.....etc. Ming Feng's lighting products enjoy a wide range of applications. Like workshop, staium, railway, building, airport , tunnel and mines. Our factory locates between Shenzhen port and Guangzhou, it’s convenient to visit our factory and delivery the container to all around the world based on Shenzhen port.

Ming Feng Lighting Co., Ltd warmly welcome all the partners visit our factory and share the ideas of the LED light. Ming Feng Lighting factory stays with you all the time to share the happiness of the LED light, let’s work together to create an outstanding future.

   ​
