Factory Price UL Listed 0-10V Dimmable LED Emergency Panic Driver
with 90-Minute Discharge Time 5Year Warranty for Down Light Highbay
Light Tube Light
1.UL Listed for us and canada
2.Listed to UL924 and tested to CSA C22.2 NO.141Field
or factory installation
3.High voltage output
4.Low energy consumption CEC compliance
5.Constant output power
6.Self-testing
7.Battery:over temperature protection
Technical Data| Input voltage | 100-347Vac, 50/60Hz |
| Input current | 200mAmax |
| Input Power rating | 12W max. |
| Output Voltage | 170Vdc |
| Emergency Power | 15W/25W/30W/40W |
| Recharge Time | 24Hrs |
| Discharge Time | 90minute |
Ambient Temp | 32~122 F(0....+50 ºC) |
| Warranty | 5 Years |
| Battery | Li-ion |
| Weight | :3.66 lbs(1.4kg) |
This product is a MF LED Emergency Driver MF-EM-xxW-170 with self -
detection, constant - power emergency output, built - in battery
and multi - protection functions. It suits for LED fitting with
external LED driver. The relevant application scenarios are as
follows:
Emergency Lighting for LED Fixtures: When the power is off, it can provide emergency power for LED
lights. For example, in case of a power outage in buildings such as
offices, homes, shops, and public facilities like schools and
hospitals, the LED lights equipped with this emergency driver can
still work, ensuring basic lighting needs are met.
Application Scenarios:
1.In educational institutions like schools, it ensures students and
staff can safely evacuate during a power outage, especially in
classrooms, corridors, and stairwells.
2.For hospitals, where continuous lighting is crucial for patient
safety and medical operations, this emergency driver powers
emergency lights in patient rooms, operating theaters, and
emergency exits.
3.In transportation hubs such as subways, train stations, and
airports, it lights up exit signs and provides general emergency
lighting, helping passengers find their way out quickly during
emergencies.
4.Shopping malls and supermarkets benefit from it as well. During
power failures, it illuminates aisles, exits, and emergency exits,
ensuring the safety of shoppers and employees.
5.Offices, factories, hotels, basements, and parking lots also rely
on this product. In offices, it allows employees to safely leave
the building; in factories, it prevents accidents during power
outages; in hotels, it helps guests evacuate; and in basements and
parking lots, it provides necessary lighting for people to move
around safely.
6.In all public places, this emergency driver is essential for
powering emergency lights, exit sign lights, and emergency exit
lights. These lights include exit sign emergency lights, emergency
LED lights, LED emergency lamps, as well as rechargeable emergency
lights, battery backup lights, and emergency lamps.
